RJ-100SC & RJ-100SC Ultra Compactor

Model: RJ-100SC Compactor

Our RJ-100SC Self-Contained Compactor / Container makes handling wet or dry waste simple.

It is easy to load from both the ground and dock levels. In addition, a hopper can be used to double or triple the loading capacity. Waste can be fed continuously while the unit is cycling. The 22-ton (19,958 kg) plus crushing power of the RJ-100SC will reduce your refuse to a fraction of its original size. The universal double-end pickup and dock-friendly design make the RJ-100SC ideal for dock-fed applications. Other features include fire hose connections on each unit, hinge grease fittings, and ground and guide rollers.

STANDARD ON ALL RJ-100SC COMPACTORS

Reliable, solid state circuitry eliminates all pressure and limit switches
CYCON’s no-shock cycle control extends cylinder and hose wear life
Automatic “container full assurance system” — the ram dwells against the load at full pressure, resulting in better compaction
Smoother running, quieter operation

Advanced hydraulic design enables the system to operate at minimum pressure levels except when actually packing solid waste
More accurate advanced Warning or Container full options
Dramatically improved cold weather performance

P-SEAL

The P-shaped Door Seal is specially designed for portable compaction containers to provide a superior watertight closure. The mounting is engineered for quick and easy installation when replacement is necessary, requiring no field fitting, cutting, or welding.

DOUBLE-HINGE WITH BRONZE BRUSHING

Every RJ-100SC compactor is tested for watertightness before leaving the factory. Liquid retention is ensured by the incredible Double-Hinge. It creates uniform seal compression while eliminating the seal “scrubbing” and damage so often encountered with competitive designs. The Double-Hinge also saves expensive driver and truck time because only one easy-to- operate ratchet makes it work.

BUBBLE GATE AND AUTO RELATCH

The innovative “Bubble Gate” adds a full cubic yard to container capacity. Superior compaction ratios result from its special curved shape. These two unique benefits reduce costs of disposal.

The ultimate in latch systems, the “Auto Relatch” eliminates the need to hold the door while operating the latch ratchet. This design enables the operator to use both hands on the ratchet.

QWIK CLEAN TANK®

The Qwik Clean Tank with exclusive Trash Check™ is a standard feature on the DRC II. It funnels any liquid seepage occurring during compaction into an enclosed area underneath the charge box floor. The liquid is automatically discharged at the disposal site, in effect flushing the container and the area behind the ram.

CYCON CYCLIC CONTROL SYSTEM

Standard on all DRC Compactors

Reliable, solid state circuitry eliminates all pressure and limit switches
CYCON’s no-shock cycle control extends cylinder and hose wear life
Automatic “container full assurance system” — the ram dwells against the load at full pressure, resulting in better compaction
Smoother running, quieter operation

Advanced hydraulic design enables the system to operate at minimum pressure levels except when actually packing solid waste
More accurate advanced Warning or Container full options
Dramatically improved cold weather performance

Model: RJ-100SC Ultra Compactor

The RJ-100SC Ultra is loaded with added value features that are unique to compactors of this type.

A new, universal power unit with a programmable micro PLC is among these features. This solid state micro controller will also allow for diagnostics capabilities. The power unit also features a highly efficient flooded suction pump and a fused disconnect switch.

RJ-100SC ULTRA COMPACTORS FEATURES

Large 35 ” x 60 ” feed opening to handle bulky items!
Continuous feed capability – even while compactor is operating!
Adaptable to special loading systems such as large capacity hoppers, security chutes or total enclosures.
Total odor and pest control via Marathon’s Ozone Odor Control option Easy loading from either ground or dock level.

Standard double-end pick-up – the unit can be loaded for hauling from either end. This is especially useful if installed perpendicular to a dock.
Over 22 tons of crushing force to reduce refuse to a fraction of its former size saving valuable space.
Easy and fast installation! Installation costs are cut in half over conventional compaction systems.
Factory testing to assure leakproof construction.

OFFERING MAXIMUM BENEFITS FOR:

Malls
Supermarkets
Large Restaurants
Hotels

Hospitals and Institutions
Resorts and Food Processors
Easy and fast installation! Installation costs are cut in half over conventional compaction systems.
Engineering

Remote Power Pack

The Remote Power Pack, separate from the compactor/container, remains free of damage caused during hauling to and from disposal sites and free of problems caused by landfill dust. No electrical connections to make or break — two simple-to-use, hydraulic quick disconnects couple the power unit to the packing head. Weather Cover and the UL® & CUL® listed Motor Control Panel are standard equipment.
